Jak metoda lisování ušetřila 4 miliony Kč
a dokončila projekt o 3 měsíce dříve?
How press-fit saved 4 million CZK
and finished the project 3 months early?
Wie das Pressverfahren 4 Millionen CZK sparte
und das Projekt 3 Monate früher abschloss?
Reálný projekt ze zahraničí: Průmyslový areál s 28 skladovacími tanky čelil kritickému rozhodnutí. Urgentní potřeba rozšířit skladovací kapacitu z důvodu před kritickým termínem sklizně úrody. Příklad z praxe s obdobným lisovacím systémem ilustruje potenciál metody lisování obecně. Data nejsou měřena na Tavinox. Real foreign project: An industrial facility with 28 storage tanks faced a critical decision. Urgent need to expand storage capacity before a critical harvest deadline. A practical example with a similar press-fit system illustrates the potential of the press method in general. Data not measured on Tavinox. Reales Auslandsprojekt: Eine Industrieanlage mit 28 Lagertanks stand vor einer kritischen Entscheidung. Dringender Bedarf, die Lagerkapazität vor einem kritischen Erntetermin zu erweitern. Ein Praxisbeispiel mit einem ähnlichen Presssystem veranschaulicht das Potenzial der Pressmethode im Allgemeinen. Daten wurden nicht an Tavinox gemessen.
58 %
RychlejiFasterSchneller
37 %
LevnějiCheaperGünstiger
14
O týdnů dříveWeeks earlierWochen früher
4.4 mil Kč
UšetřenoSavedGespart
Průběh projektu Project timeline Projektablauf
1. Dilema1. Dilemma1. Dilemma
Technický ředitel váhal mezi tradičním svařováním a lisováním. Co je rychlejší a levnější?The technical director was torn between traditional welding and press-fit. Which is faster and cheaper?Der technische Direktor schwankte zwischen traditionellem Schweißen und Pressen. Was ist schneller und günstiger?
2. Test2. Test2. Test
Identické požadavky, paralelní realizace, objektivní srovnání. 5 tanků svařováním vs. 4 tanky lisováním. Ať vyhraje lepší.Identical requirements, parallel execution, objective comparison. 5 tanks by welding vs. 4 tanks by press-fit. May the best win.Identische Anforderungen, parallele Ausführung, objektiver Vergleich. 5 Tanks durch Schweißen vs. 4 Tanks durch Pressen. Der Bessere möge gewinnen.
3. Výsledek3. Result3. Ergebnis
Lisování začalo o 3 týdny později, a přesto po 10 dnech lisováním byly 4 tanky dokončeny. Svářeči teprve dokončovali 1. tank. Rozhodlo se, že se zbylé tanky budou lisovat obdobným systémem, jako je TAVINOX. Odhad lisování se dokonce snížil o 10% nákladů.Press-fit started 3 weeks later, yet after 10 days, 4 tanks were completed by press-fit. Welders had only just finished the 1st tank. The remaining tanks were to be installed by press-fit, similar to the TAVINOX system. The press-fit estimate even decreased by 10% in costs.Das Pressen begann 3 Wochen später, und dennoch waren nach 10 Tagen 4 Tanks durch Pressen fertiggestellt. Die Schweißer hatten gerade erst den 1. Tank fertiggestellt. Es wurde beschlossen, die restlichen Tanks mit einem ähnlichen System wie TAVINOX zu verpressen. Die Pressschätzung sank sogar um 10% der Kosten.
Pohled na část realizovaného areáluView of part of the completed facilityBlick auf einen Teil der fertiggestellten Anlage
Svařování (Odhad)Welding (Estimate)Schweißen (Schätzung)
24 týdnů realizace24 weeks of work24 Wochen Ausführung
Nestihl by se termínDeadline would not be metTermin wäre nicht eingehalten worden
Lisování (Realita)Press-fit (Reality)Pressen (Realität)
10 týdnů realizace10 weeks of work10 Wochen Ausführung
Včas hotovoCompleted on timeRechtzeitig fertig
Úspora nákladů lisováním o 37 % Cost savings with press-fit: 37% Kosteneinsparung durch Pressen: 37 %
Zatímco svařování se prodražilo o 15 % oproti plánu,
lisování zlevnilo realizaci o 10 % oproti původnímu odhadu.
While welding exceeded the budget by 15%,
press-fit reduced costs by 10% compared to the original estimate.
Während das Schweißen das Budget um 15 % überschritt,
reduzierte das Pressen die Kosten um 10 % gegenüber der ursprünglichen Schätzung.
| PoložkaItemPosition | SvařováníWeldingSchweißen | LisováníPress-fitPressen | RozdílDifferenceDifferenz |
|---|---|---|---|
| Odhad nákladů na 1 tankEstimated cost per tankGeschätzte Kosten pro Tank | 446 400 Kč | 360 000 Kč | 86 400 Kč |
| Reálný náklad na 1 tankActual cost per tankTatsächliche Kosten pro Tank | 515 088 Kč | 323 460 Kč | 191 628 Kč |
| 23 tanků celkem23 tanks total23 Tanks gesamt | 11 847 024 Kč | 7 439 580 Kč | 4 407 444 Kč |
* Data vychází realizovaného projektu ze zahraničí 2017Data from a foreign project completed in 2017Daten aus einem ausländischen Projekt aus dem Jahr 2017
Výsledek projektuProject resultProjektergebnis
10 týdnů místo 2410 weeks instead of 2410 Wochen statt 24
Projekt dokončen o 14 týdnů dříve (58 % rychleji) díky lisování.Project completed 14 weeks earlier (58% faster) thanks to press-fit.Projekt 14 Wochen früher abgeschlossen (58 % schneller) dank Pressen.
